INFORMATION

;Directory
NaD/scan01

;Target
AR13738

;Observation start time
2024.07.13 09:17:52JST

;Comment
Observation end time
2024.07.13 10:18:27JST
Clouds often passed.
Tracking in Telescope-mode, not PG-mode

;Information
Line : Na I D
Slit length :  50.00 : [mm]
Slit width  :  0.10 : [mm] : 0.64 : [arcsec]

Radius            :  xx: [min] :  xx : [arcsec]
Polar angle	  : xxx : [deg] :  xx : [min]
Inclination angle :  074 : [deg] :  06 : [min]

Speed1 : 10000 : [pps]
Speed2 :  1100 : [pps]
Triger :    ON
Swing  :   120 : [arcsec]

Exposure :    90 : [ms]
Gain     :     0

REFSPEC

Javascript Moive: click each image

MOVIES
Na I D1 line center Intensity

Na I D1 ±0.1Å Intensity (I-0.1Å+I+0.1Å)

Na I D1 line center Doppler

Na I D1 Whole Core Intensity

Na I D2 line center Intensity

Na I D2 ±0.1Å Intensity (I-0.1Å+I+0.1Å)

Na I D2 line center Doppler

Na I D2 Whole Core Intensity

Na I D Intensity ratio (Na I D2/Na I D1)
