Hida/DST Spectrum Observation

20070603 21:23UT

Camera: GE1650
Frame rate: > 12[Hz]
FOV: 128" (slit direction)
Position: Radius/13'08"->+120",Polar angle/80deg10',Inclination/350deg08'
Exposure Time: 80[ms]
Slit width: 0.1[mm] (0.64")

Javascript Moive: click each image

HaIntensity (center width:0.1A)
The first half of each scanThe latter half of each scan

HaIntensity (I_r+I_b)(-0.5&+0.5)
The first half of each scanThe latter half of each scan

HaIntensity (I_r+I_b)(-0.8&+0.8)
The first half of each scanThe latter half of each scan

HaDoppler (center)
The first half of each scanThe latter half of each scan

HaDoppler/ratio[(I_r-I_b)/(I_r+I_b)](0.5)
The first half of each scanThe latter half of each scan

HaDoppler/ratio[(I_r-I_b)/(I_r+I_b)](0.8)
The first half of each scanThe latter half of each scan

HaIntensity (center width:0.25A)
The first half of each scanThe latter half of each scan

HaIntensity (wing)
The first half of each scanThe latter half of each scan
